Product Details
Place of Origin: China
Brand Name: VBE
Certification: ISO9001
Model Number: VBE-3F15
Payment & Shipping Terms
Minimum Order Quantity: 1Set
Price: Customizable
Packaging Details: Wooden Packing
Delivery Time: 6 to 8 working weeks
Payment Terms: T/T
Supply Ability: 50000 Sets per year
Product Name: |
Anti-Drone Flashlight |
Jamming Distance: |
Up To 300 Meters |
Dimentions: |
66*66*280mm |
Weight: |
1kg |
Power Consumption: |
30W |
Build-in Battery: |
220VAC/12VDC |
Color: |
Black |
Product Name: |
Anti-Drone Flashlight |
Jamming Distance: |
Up To 300 Meters |
Dimentions: |
66*66*280mm |
Weight: |
1kg |
Power Consumption: |
30W |
Build-in Battery: |
220VAC/12VDC |
Color: |
Black |
Anti-Drone Flashlight with 1000LM Strong Lighting & Drone Jamming distance up to 300 meters, Flashlight Drone Jammer
Model: VBE-3F15
Introductions
The Anti-Drone Flashlight designed for blocking commercial drone signals.
Jamming radius of this device depends on several conditions such as transmitter frequency and output power, distance to receiver, and obstacles between, etc.
Because of the variety of jamming targets and a wide range of uncertainties, we have adopted the more advanced and effective jamming signal modulation method, which will increase the jamming efficiency in each band.
The Flashlight with 1000lumen strong lighting.
Features
Advanced Jamming technology for high efficiency;
Slow start up design of circuit to make the device work stably;
Perfect Self Protection: Over Heat protection, Over current protection, High input Voltage and low Voltage protection, VSWR protection
Hidden Design
Easy Operation
Strong lighting Flashlight function
Applications
To block commercial used drones for any sensitive locations, like prisons, airports, scientific research centers, detention houses, courthouses, labor camp, military bases, etc.
Technical Specifications:
RF Characteristics:
Total Output Power: Up to 15W
Jamming distance: up to 300 meters depending on the several conditions such as transmitter frequency and output power, distance to receiver, and obstacles between, etc.
Internal Modulation: FM Hopping Frequency and Sweeping
Power Supply: 220VAC/12VDC
Power consumption: 45W
Jamming target: commercial drones
Power Amplifier Protectors:
A. Over- Heat protection – Thermal protector
B. Over current protection
C. High input Voltage and low Voltage protection
D. VSWR protection: against antenna miss-match including open and short circuit
Cooling: Heat sink and air forced fans
Physical Data:
Net Weight of Jammer Host: approx 1kg
Dimension: 66*66*280mm
Proof Level: IP65
Environment of operation:
Operating Temperature: -10ºC - +50ºC
Humidity: up to 85%
Battery:
Battery type: Lithium Battery
Battery quantity: 1pcs
Battery working time: >=30 min
Low battery warning: available
Battery fast change: available
Spare Battery: optional
Flash Light:
Output Power: 10w
Lumens: 1000LM
